Gladiator EVO 'Space Combat Edition' Premium
Gladiator EVO 'Space Combat Edition' Premium
The Gladiator EVO Premium is the basis of a modular VKB flight control system.
The 'Space Combat' grip is the most versatile of our grips and is equally suitable for flight and space simulation games.
With lots of buttons and axes you may configure the controller to your own personal needs and depending on the aircraft or spacecraft you fly.
For a detailed product description and to find out what's new about the EVO compared to the superseded NXT controllers, please click here.
Content
- 1 GNX SCG Premium Grip (Left or Right)
- 1 GNX EVO Base
GNX SCG Premium Grip
- Compact grip design - perfect for tabletop joysticks
- Lockable Twist (Z-axis) with contactless MaRS sensor
- 1 Dual Action Trigger
- 1 Rapid Fire Trigger
- 3 Hat switches with centre push (4-way)
- 3 buttons
- 1 analog mini stick with center push (8-way)
- Programmable red colour LED
- 2 interchangeable palm rests (total 3 palm-size adjustments)
- Programmable RGB LED
- Extra button module for C1 position
- Extra hat switch module for A1 position
- Trigger cover
GNX EVO Base
- 2 Contactless MaRS sensors on X and Y axes
- 1 Auto-centreing 3-position switch
- 1 Throttle wheel
- 1 Rotary encoder
- 3 buttons
- Gimbal with ball bearings
- Adjustable dry clutches for user-tunable load
- 2 Programmable single-colour LEDs
- Tabletop base steel plate
- Operating manual
- Set of soft springs
- Set of strong springs
- Spring extractor tool
- Set of screws
- Screwdriver
- USB cable (180cm/70inch)
- Cable holder tool
General Specifications
- Base & Grip made from industrial grade ABS
- Gimbal made from glass-fiber-reinforced PA
- Tabletop base plate made from steel
- 32-bit ARM Controllers inside base and grip
- ALPS buttons (Japan OEM) for extended longevity
- Contactless MaRS sensors with High Resolution
- Plug & Play with Driver-Free Installation (Recommended for Most Users)
- Firmware Upgrade via USB
- Onboard Memory for Storing Profiles
- Optional Programming Software Available (For Advanced Users)
Dimensions
-
Height table top to top of grip: 23.5cm approx.
-
Base plate length (deep): 18.5cm approx.
- Base plate width (left to right): 14.5cm approx.
Warranty
-
1 Year
Compatible with
- STECS Throttles (click here)
- GNX Extension modules (click here)
- T-Rudder Mk.IV (click here)
- Universal Controller Mount UCM-S GL (click here)
Instructions
Downloads
Please visit the Downloads section for the latest firmware and tools.
IMPORTANT:
VKB controllers are delivered with the latest firmware installed and flashing is not required for initial setup.
EVO Product line
This is SUCH an upgrade from my last stick. The construction is amazing; It feels so good in hand.
I used the VKB Gladiator joystick to replace a mouse for Elite Dangerous, and I can accurately select the various minutiae of the ED interface and map system more efficiently than i could with my mouse. It is the most comfortable joystick I've ever owned, and I'm never going back.
Before purchasing the Gladiator EVO, I was using a Logitech Extreme Pro which was inherently instable due to its use of potentiometer and it also didn't a good job keeping its center position which made it very difficult to use it in a sensitive situation such as landing or performing tight maneuvers in flight sims.
Now with my new purchase, I'm super happy that I am able to maintain accurate input on my controls thanks to VKB's quality sensors and controller units.
Moreover, it comes in very handy that I'm able to modify the unit to my taste using the included kits such as tensions, weights and even the buttons.
Finally, being able to re-map / assign different functions to all 50+ buttons AND being able to save/load the configurations is just mind blowing.
I highly recommend this unit to anyone who is a serious flight simmer / gamer needing a professional touch in their setup. (Currently playing the following titles using this superb stick : X-Plane 12, MSFS, Elite Dangerous, Arma 3, etc.)
I purchased this for Comanche (not supported) and easy flight games but have not found one game that recognises the joystick. I have searched the internet for a list of supported games but found none. Flight simulators might support and recognise the stick but they don't interest me. Yes there are instructions on Steam that involve editing system files (.ini) but I don't think anyone should have to do that. It's like game developers don't even know this joystick exists.
Hi Alan,
Thank you for your review. We highly appreciate your feedback.
VKB joysticks and controllers work in all games which provide joystick support. In most of these games the user has to bind the joysticks before playing.
We would like to get a better understanding where your issue is.
Can you please send us an email at support@vkb-sim.com.au and let us know which games give you troubles?
We can then address your issue specifically.
Thank you in advance.
Lots of adjustments and buttons. I use it predominantly for Helicopters in msfs so I took the tension springs off and tightened the dampers up a bit. Would love a 10cm extension though.
We're so glad to hear that you are enjoying your Gladiator EVO 'Space Combat Edition' Premium joystick! We pride ourselves on providing a versatile and high-quality product for our customers.
It's great to hear that the adjustments and buttons are meeting your needs, and we're happy to know that you have found a way to customize the stick for your specific use in msfs. We appreciate the suggestion for a 10cm extension and will definitely take it into consideration for future improvements.
Thank you for choosing our product and for taking the time to leave a review. Happy flying!
